ECG Machines >HartPro 12 Delux



The HartPro series of ECG Machines are designed to be robust and easy to use even in the most demanding emergency environments.

It's large color display will ensure that you don't miss a beat and clear thermal printing will ensure you pick up any and all anomalies.

The HartPro series of ECG Machines are the pinacle of modern electro-kardiograph technology. It has a full range of features including interpretation, memory, data management and simultaneous 12 leads acuisition.

Simply put, the HartPro series are the staple for every Hospital.


Download Brochure Here
  • 10"TFT Color LCD shows the working status and ECG waveform. Check the waveform before printing to save record paper.

  • 12 Leads ECG simultaneous gathering, digital signal processing, to get the ECG waveforms of higher quality through the AC, DFT and EMG filtering of the ECG signals.

  • Simultaneous display of 3/6/12 leads ECG waveform, and the state of printing mode, sensitivity, speed, filter etc, to be easy for contrast diagnosis.

  • Multiply printing modes and formats, including 12*1, 6*2+1(rhythm lead), 6*2, rhythm 12, rhythm 10, rhythm 8, rhythm 6, manual and freeze, etc. The length of printed wave can be adjusted and simultaneity the function of periodic printing is offered to satisfy different applications.

  • The instrument has the functions of auto-analysis and auto-diagnosis of regular ECG waveform parameters, provides measurement parameters such as HR, P-R interval, P Duration, QRS Duration, Q-T interval, Q-Tc, P Axis, QRS Axis, T Axis, R(V5), S(V1), R(V5)+S(V1), etc and auto-diagnosis conclusion to reduce doctor's burden.

  • AC/DC power supply. Built-in rechargeable lithium polymer battery. At the best DC state, it can standby for 4 hours, print continually for 90 min, and print 150 pieces of ECG waveform to satisfy the need of visiting patients and physical  examination.
  • Built-in MSF, can store more than 1000 cases, convenient for doctor's case review and information statistics.
    System provides Chinese/English/Spanish/Turkish operation interface and can print multiply languages report.
    System provides multiply printing speeds, including 5mm/s, 6.25mm/s, 10mm/s, 12.5mm/s, 25mm/s, 50mm/s, and abstract conclusion graph printing.
